Evaluation PCB for WHY5640 Temperature Controller

Out of stock

CONTACT FOR QUOTE

Evaluation PCB for WHY5640 Temperature Controller

    Out of stock

    CONTACT FOR QUOTE

    Evaluation PCB for WHY5640 Temperature Controller

      Out of stock

      CONTACT FOR QUOTE

      Contact Factory for High Volume Pricing
      Price adjustments will be reflected in the cart. For availability information please contact us.

      All prices are in US dollars. Prices do not include shipping charges. All prices will be confirmed at time of shipment and may include pass-through tariff estimates.

      If ordering from or shipping to Australia, China, or Hong Kong, please contact your distributor.

      Use the WHY5690 Evaluation Board to rapidly prototype a complete temperature control system using the WHY5640 Temperature Controller. Drive current to a thermoelectric or resistive heater and control temperature using thermistors, or 100 Ω Platinum RTDs. Onboard switches, connectors, and trimpots make configuration and operation simple. The WHY is not included. There is a current enable switch with LED indicator. Complete cable sets are included. Power and monitors are on one connector. Load and sensor pins are on a second connector. To calculate sensor resistance (therefore temperature), use two monitors and an equation from the datasheet. Adjust temperature setpoint using an onboard trimpot. Measure the resistance while a switch removes the trimpot from the circuit then switch to the “Run” position to resume operation. Two SMT test points simplify the resistance measurement. Other trimpots configure heat and cool current limits, proportional gain and integrator time constant. An onboard fan connection can power a WXC303 or WXC304 (+5 V or +12 V DC fan) attached to a WHS302 heatsink. Free, effective, and responsive technical support is available to simplify integration of Wavelength products into your OEM design. Standard product can be easily modified to meet your application requirements.

      Size: 2.25 x 2.25 x 1.1″ (with WHY5640 installed)
      57 x 57 x 28 mm

      Top View of WHY5690

      Top View of WHY5690

      NOTE: The WHY5640 and WTC3243 do NOT have the same pin configuration. See Datasheet for pin configuration. The WHY5690 evaluation board cannot be used with the WTC3243.

      DATASHEETS
      MECHANICAL / CAD DRAWINGS
      DESIGN TOOLS
      ACCESSORIES
      KITS
      RELATED PARTS
      SKUDESCRIPTIONPRICEIMAGE
      WHY5640 WHY5640 2.2 A Temperature Controller $78.00
