NEW Case Study: High-Definition Video Broadcasting with QCLs

Free-space communications can overcome the logistical difficulties of broadband connections in remote or rural areas. By using long wave infrared (LWIR) quantum cascade lasers (QCLs) as optical sources, high data rates can be transmitted error-free, eliminating the need for physical connections.

By experimenting with live video broadcasting at different levels of video formats, researchers realized free-space live video broadcasting with a room temperature QCL at a wavelength of 8.1 μm. The high definition video format (1280 pixels x 720 pixels) is transmitted at a data rate of 1.485 Gbits/s without any errors.

High definition video broadcasting requires high precision and stable control of the quantum cascade laser in signal transmission.

Wavelength Electronics’ QCL driver, QCL2000 LAB, enabled precise current control with minimal electronic noise from the QCL. The driver also provides analog modulation of up to 2-3 MHz for wavelength modulation, allowing the QCL to emit a constant, uninterrupted signal that is subsequently modulated for communication purposes. The transmission was studied for several hours at a time, indicating the long term stability of the QCL2000 LAB current driver. In addition, the stability of the QCL bias current is critical for consistent electrical bandwidth.

The low noise, high stability QCL2000 LAB, can precisely deliver up to 2 A to the laser. This benchtop instrument exhibits noise performance of 1.3 μA RMS up to 100 kHz with an average current noise density of 4 nA/√Hz. Wavelength Electronics’ QCL driver enables high definition video broadcasting with a data rate of 1.485 Gbits/s with low noise and stable laser output. This makes the developed QCL system a reliable tool for real field applications in free-space communication.

The complete case study is available as CS-LD07.

NEW Case Study: Using QCLs for Studying Exceptional Point Singularities

The effects of exceptional point (EP) singularities can naturally be seen in many applications in physical problems: mechanics, electromagnetism, atomic and molecular physics, quantum phase transitions, quantum chaos, and much more. Researchers from Switzerland have developed a more practical and robust method for studying these effects. As lasers provide an ideal system for direct observation and engineering of spectral singularities, two dual section distributed feedback (DFB) quantum cascade lasers (QCLs) were designed with Fabry-Perot modes and quarter wave shifted (QWS) DFB modes.

By varying the physical location of the QWS defect as well as the injection current, researchers were able to observe and study EPs based on the coupling parameters of the system. These results show that the developed QCL is a perfect platform to study and further the knowledge of EPs and the effects they have between the weak and strong coupled regime of a laser. Due to the temperature dependence on the injection current of the QCL, researchers upgraded the electronic drive equipment to utilize the high performance capabilities of Wavelength Electronics’ QCL2000 OEM driver. This critical component enables the sensitive measurements and analysis of EP degeneracy in QCLs and other non-Hermitian systems.

Because the EP degeneracy is lifted at only a certain applied current, ultra-low noise laser drivers were needed. Wavelength Electronics’ driver limits noise produced to as low as 1.3 μA RMS up to 100 kHz and an average current noise density of 4 nA/√Hz. With an output of up to 2 A and stability around 10 ppm long-term, the QCL2000 provided the stability and flexibility needed. This stability allowed researchers to discover the precise applied current at which the EP degeneracy was lifted.

The complete case study is available as CS-LD06.

January 2023

Visit Us at PW2023, CASE STUDY: Using QCLs for Studying Exceptional Point Singularities,CASE STUDY: A Ray Tracing Approach to Capillary-Based Backscattering Interferometry

Continue reading

NEW Case Study: A Ray Tracing Approach to Capillary-Based Backscattering Interferometry

Capillary-based backscattering interferometry has been used as a highly sensitive refractive index sensing tool to measure molecular binding. Generally, ray tracing is used to simulate the backscattered light from the specific capillary. Previous ray tracing models do not account for polarization effects, capillary dimensions, material choices, and other parameters that could change the interference patterns captured.  Researchers from the United Kingdom have developed a comprehensive ray tracing model including many parameters not previously reported.

The significance of the inner diameter, outer diameter, and the refractive index of the capillary material are shown to heavily influence the interference pattern. Potential designs are explored to measure sensitive temperature changes, and therefore refractive index changes, based on capillary characteristics.

Due to temperature dependence of the refractive index of the solution inside the capillary and the capillary itself, the aluminum stage that holds the capillary needs to be maintained at a stable temperature. Wavelength Electronics’ WTC3243HB temperature controller can achieve 0.0009ºC temperature stability when coupled with a Peltier thermoelectric module. This controller, an adaption of the standard WTC3243 controller, operates from 3.6 V, Lithium-Ion batteries. The WTC3243HB ensured stable refractive index of the solution inside the capillary, correlating to a more stable and repeatable backscattering light collection from the camera.  By using the WTC3243HB temperature controller, researchers were able to maintain consistent and stable temperatures of the capillary and the solution inside the capillary in this backscattering interferometer, beneficial for measuring molecular binding via interferometric refractive index sensing.

The complete case study is available as CS-TC07.

September 2022

CASE STUDY: Deployable Scintillometer for Ocean Turbulence Using Superluminescent LED, CE/RoHS Compliance is Coming for the LFI3751, CASE STUDY: Rapid Transitions of Thermo-Responsive Polymer Networks, Distributor Spotlight: Optron Science, Inc.

Continue reading

NEW Case Study on Rapid Transitions of Thermo-Responsive Polymer Networks

Responsive polymers are used in drug delivery, switchable biocompatible coatings, and advanced bio-interfaces in bioanalytical devices. Thermo-responsive polymers, where changing the temperature stimulates changes in the polymer properties, are the most common in biomedical applications. All thermo-responsive polymers have a lower critical solution temperature (LCST). Above or below this temperature determines the state of the polymer.

Many different external parameters affect the response speeds of the collapsing and swelling states in thermos-responsive polymers. With a plasmonic heating technique that optically excites localized surface plasmon (LSP) modes on the surface of Au nanoparticles, the temperature of the polymer hydrogel layer can be precisely controlled with respect to the ambient bulk temperature. By testing different bulk temperatures, longer heating beam pulses, and a variety of temperature change increases, researchers realized response times as low as 1.5 ms for the collapsing state and single digit milliseconds for the swelling state of the polymer hydrogel. With the investigated complex and different response times of thermo-responsive polymer networks, advances can be made in biomedical and miniature actuator applications.

The effect of the ambient bulk temperature on the sample was critical to the speed and timing of the thermo-response. To control this temperature, researchers used Wavelength Electronics’ LFI-3751 temperature controller to operate a Peltier device attached to the flow cell and substrate with the nanoparticle and polymer hydrogel layer. The high performance LFI-3751 temperature controller ensured constant and stable temperature of the polymer networks. By controlling this temperature and carefully increasing or decreasing above or below the LCST, researchers found the effects on ambient bulk temperature paired with plasmonic heating on thermo-responsive polymer networks.

The complete case study is available as CS-TC06.

NEW Case Study on Deployable Scintillometer for Ocean Turbulence Using Superluminescent LED

The use of imaging and free-space optical communication is increasing in underwater applications. Optical communication and inspection of piers, pilings, or ship berthing areas requires overcoming the constantly changing characteristics of the water, especially in the ocean. Researchers from the Naval Information Warfare Center Pacific (U.S.) and the University of Central Florida have designed and developed new algorithms and a portable scintillometer to characterize ocean turbulence for imaging and free-space optical communication applications. Suspended particulates scatter light and organic material absorbs light in the ocean, but ocean turbulence can limit resolution of imaging due to temperature gradients (thermocline) or salinity. As turbulence is not constant in relation to water depth, a real-time characterization of turbulence conditions is needed. With this design, the refractive-index structure parameter (Cn2) and the inner scale of optical turbulence (ℓ0) were measured at 1.9 x 10-11 m-2/3 to 2.3 x 10-10 m-2/3 and 0.1 to 0.3 mm, respectively, correlating to measured thermocline parameters.

A superluminescent light emitting diode (SLED) served as the scintillometer source for optical ocean turbulence characterization in place of the commonly used laser diode. The SLED still requires stable current and temperature control in the portable design. Wavelength Electronics’ LDTC1020 laser diode and temperature controller provided the closed-loop control of the SLED’s drive current and temperature with minimal noise and high temperature accuracy. The LDTC1020 aided in the small footprint and mass required for the portable system.

The complete case study is available as CS-LDTC11.

NEW Case Study on Improved Gas Concentration Model Accuracy in Wavelength Modulation Spectroscopy

Laser absorption spectroscopy is built upon the properties of the Beer-Lambert Law, in the most basic form, relating the absorption of light and the concentration of a particular gas. Researchers from China have developed a new concentration inversion model for wavelength modulation spectroscopy (WMS) techniques in tunable diode laser absorption spectroscopy (TDLAS) applications. Traditional models do not take into account variations of the modulation depth in the second harmonic signal of the laser, thereby increasing the error of the measurement and decreasing the accuracy of the system. Through simulations and controlled experiments measuring CO gas concentrations, researchers achieve root-mean-square error (RMSE) of the gas concentration measurements of 5.468 × 10-5 with relative error of < 0.37% using an improved model of concentration inversion with modulation depth as a variable parameter. This model produces almost an order of magnitude better RMSE and almost five times better relative error, making this applicable in fields such as industrial and environmental gas monitoring.

Finding gas concentrations in industrial and environmental applications requires high precision, high accuracy, and stable temperature control of the laser diode used for the TDLAS. Wavelength Electronics’ laser drivers and temperature controllers enable the sensitive measurements and experiments for concentration inversion models based on second harmonic valley spacing, useful for gas detection in the commercial world. The stability of the laser diode in gas detection is critical, both in current stability of the injection current and the temperature control.

Wavelength’s low noise, high stability laser diode driver and temperature controller, the LDTC0520, can precisely deliver up to 500 mA to the laser and maintain the laser temperature with stability better than 0.005ºC for 1 hour on ambient temperature. It can provide up to ±2.2 A of current to a thermoelectric with both heating and cooling current limits. The PI control loop offers maximum stability while maintaining efficiency. The benefits of the temperature controller can also help narrow linewidth and can ensure the wavelength does not have any unwanted fluctuations. The laser diode’s life and performance are improved by tighter and more precise control of the laser heatsink temperature.

The complete case study is available as CS-LDTC10.

April 2022

Israeli Consul General Tour, CASE STUDY: Improved Gas Concentration Model Accuracy in Wavelength Modulation Spectroscopy, Coherent Radar Lasers in Big Sky Montana, CASE STUDY: CO Detection in SF6 Using Quartz-enhanced Photoacoustic Spectroscopy

Continue reading

Opto-electronics Qualification: NASA Goddard

Optoelectronic qualification requires more than a laser source—it requires precise, repeatable control of that source. Noise, drift, and instability in the laser drive electronics can affect optical output and complicate the characterization of the device or system under test.
