CATEGORIES
Thermal Paste
CAN BE USED WITH
- HTC1500 1.5 A Low Profile OEM Temperature Controller
- HTC1500-62 1.5 Amp Low Profile OEM Temperature Controller
- HTC3000 3 A Low Profile OEM Temperature Controller
- HTC3000-62 3 A Low Profile OEM Temperature Controller
- HTC4000-62 4 A Low Profile OEM Temperature Controller
- LDTC Series 500 mA Laser Driver & Thermal Control
- LDTC Series 1 A Laser Driver & Thermal Control
- LDTC Series 2.2 A Laser Driver & Thermal Control
- LDTC Series 2.2 A Laser Driver & Thermal Control
- MPL250 250 mA Laser Diode Driver
- MPL500 500 mA Laser Diode Driver
- MPL2500 2.5A Laser Diode Driver
- MPL7500 7.5A Laser Diode Driver
- MPT2500 2.5 A Temperature Controller
- MPT5000 5 A Temperature Controller
- MPT10000 10 A Temperature Controller
- PLD5K-CH 5 A Laser Diode Driver, Chassis Mount
- PLD10K-CH 10 A Laser Diode Driver, Chassis Mount
- PLD12.5K-CH 12.5 A Chassis Mount Laser Driver
- PTC2.5K-CH 2.5 A Temperature Controller, Chassis Mount
- PTC5K-CH 5 A Temperature Controller, Chassis Mount
- PTC10K-CH 10 A Temperature Controller, Chassis Mount
- PTC10K-BOOST Booster for PTC Temperature Controller
- PTC5000 5 A PCB-Mount Temperature Controller
- PTC10000 10 A PCB-Mount Temperature Controller
- RHM5K-CH 5 A Unipolar Chassis Mount Temperature Controller
1 - 5 each
$19.00
-
1 - 5 each$19.00
-
6 - 14 each
$19.00$17.00 -
15+ each
$19.00$16.00
Contact Factory for High Volume Pricing
Price adjustments will be reflected in the cart. For availability information please contact us.
All prices are in US dollars. Prices do not include shipping charges. All prices will be confirmed at time of shipment and may include pass-through tariff estimates.
If ordering from or shipping to Australia, China, or Hong Kong, please contact your distributor.
The Thermal Paste is offered as an accessory to several Wavelength Electronics product lines to help ensure adequate thermal control during operation.
It is non-silicone. Comprised of a poly-synthetic fluid and metal oxide components, it spreads easily for excellent surface coverage and thermal conductivity of up to 3.0 W / °C.
Thermal paste should be applied thinly and evenly across the mounting area. Refer to the individual product datasheet to determine the best location for thermal paste application.
Free, effective, and responsive technical support is available to simplify integration of Wavelength products into your OEM design. Standard product can be easily modified to meet your application requirements.
Thermal Conductivity: 0.7 to 3.0 W / °C, depending on thickness and evenness of application.
Coverage area: approximately 4″ by 6″ (100×150 mm)
Chemical Composition: Poly-synthetic fluid >20%, zinc oxide >60%
This product is stable with no known hazardous components. Hazardous polymerization will not occur.
DATASHEETS
RELATED PARTS
| SKU | DESCRIPTION | PRICE | IMAGE |
| MULTI-HTSK | MULTI-HTSK Multi-Product Heat Sink |
$60.00 You save (%) |
 |
| MULTI-HTSK-HI | MULTI-HTSK-HI Heat Sink for 10 A Models |
$85.00 You save (%) |
 |
| TCS10K5 | TCS10K5 10 kΩ Thermistor (0.5x3mm) Sold in 5-packs |
$99.00 You save (%) |
 |
| TCS605 | TCS605 5 kΩ Thermistor (2.4mm OD) Sold in 10-packs |
$99.00 You save (%) |
 |
| TCS610 | TCS610 10 kΩ Thermistor (2x3mm) Sold in 10-packs |
$99.00 You save (%) |
|
| TCS620 | TCS620 20 kΩ Thermistor (2x3mm) Sold in 10-packs |
$99.00 You save (%) |
|
| TCS650 | TCS650 50 kΩ Thermistor (2x3mm) Sold in 10-packs |
$99.00 You save (%) |
|
| TCS651 | TCS651 100 kΩ Thermistor (2x3mm) Sold in 10-packs |
$99.00 You save (%) |
|
